Datasensing MSC/00-0K Sensors
Datasensing
$125.01
The Datasensing MSC/00-0K Sensors are advanced photoelectric sensors designed for a variety of applications. These sensors feature a retroreflective function with a nominal sensing distance of 4.5 meters, making them ideal for detecting objects with precision. The sensors are equipped with a red visible polarized light for enhanced detection accuracy and come with a right-angle optic for versatile installation options.
With a high switching frequency of 80Hz and a rapid response time of 6.25ms, these sensors ensure quick and reliable performance. They operate on a voltage range of 10 to 30VDC and have a low no-load supply current of ?30mA, making them energy-efficient. The sensors are designed with complete protection against electrical damage, including short-circuit and overvoltage protection, ensuring durability and longevity.
The MSC/00-0K Sensors are housed in a robust PBT/PC plug with an IP67 degree of protection, making them suitable for harsh environments. They are compatible with M12 plug connections and come with supplied accessories such as nuts for easy installation. The sensors are CE and cURus approved, ensuring compliance with international standards. With their compact dimensions of M18 x 1 /L =78.6mm and a weight of 70g, these sensors are easy to integrate into existing systems.
Ideal for applications requiring precise object detection, the Datasensing MSC/00-0K Sensors offer reliable performance with minimal maintenance, making them a valuable addition to any industrial setup.
- Nominal sensing distance:
- 4,5m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Retroreflex
- Notes:
- On RL110 reflector
- Optic position:
- Axial
- Output type:
- Decout NPN/PNP Selectable NO/NC Selectable
- Output Function:
- NO/NC Selectable
- Switching frequency:
- 80Hz
- Response time:
- 6,25ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Impulsive Overvoltage Protection
- Weight:
- 70g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug 90°
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- 25°C..+ 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cURus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
