Datasensing MSR/00-0K Sensors
Datasensing
$104.50
The Datasensing MSR/00-0K Sensors are advanced photoelectric sensor receivers designed for precision and reliability. With a nominal sensing distance of 16 meters, these sensors are perfect for a wide range of applications, offering models with diffuse, retro-reflective, polarized, through-beam detection, and background suppression capabilities. The through-beam models boast a high sensing range, while the retro-reflective models feature red visible polarized light for enhanced detection accuracy.
Equipped with a right-angle optic (MP) and fixed distance background suppression models, these sensors ensure optimal performance in various environments. The MSR/00-0K Sensors provide complete protection against electrical damage, including short-circuit and overvoltage protection, ensuring durability and longevity.
The sensors feature a Decout NPN/PNP selectable output type with NO/NC selectable output function, operating at a switching frequency of 30Hz and a response time of 16.66ms. They operate within a voltage range of 10 to 30VDC, with a no-load supply current of ? 25mA and a load current of ?100mA. The sensors are designed to withstand external light interference up to 3000lux from incandescent lamps and 10000lux from sunlight.
Constructed with a robust PBT/PC housing and PMMA active head material, the sensors are built to endure harsh conditions, with an IP67 degree of protection and compliance with EMC compatibility standards (EN 60947-5-2). They are also approved by CE and cURus, ensuring high-quality performance. The sensors come with supplied accessories, including nuts M18 x 1, and are designed for easy installation with an M12 plug at a 90° angle.
Ideal for industrial applications, the Datasensing MSR/00-0K Sensors offer reliable performance with a repeat accuracy of 5% and a thermal drift of Sr ?10% Sr, making them a versatile choice for your sensing needs.
- Nominal sensing distance:
- 16m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- Decout NPN/PNP Selectable Decout NO/NC Selectable
- Output Function:
- Decout NO/NC Selectable
- Switching frequency:
- 30Hz
- Response time:
- 16,66ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Impulsive Overvoltage Protection
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug 90°
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- 25°C..+ 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cURus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
