Datasensing QMR8/0N-0AVE80 Sensors

The Datasensing QMR8/0N-0AVE80 Sensor is a high-performance photoelectric sensor designed for precision and reliability. Featuring a miniature cubic design, this sensor utilizes diffuse reflection technology for long-distance detection, with an adjustable nominal sensing distance of up to 1 meter. It offers a repeat accuracy of 5% and sensitivity adjustment via a trimmer, ensuring optimal performance in various applications. Equipped with an NPN L/D selectable output, the sensor operates efficiently within a voltage range of 10 to 30VDC, with a no-load supply current of ?30mA and a load current of ?100mA. The sensor's robust design includes short-circuit and reverse polarity protection, as well as impulsive overvoltage protection, making it suitable for demanding environments. The QMR8/0N-0AVE80 features a radial 90° optic position and is housed in durable PA66 material, with an active head made of PMMA. It is designed to withstand shocks and vibrations, complying with IEC standards, and offers mechanical protection rated at IP67. The sensor's compact dimensions (31.2x21x13mm) and 200mm PVC cable with M12 plug ensure easy installation and integration. With LED indicators for status output and stability, the sensor provides clear visual feedback. It is capable of operating in temperatures ranging from -25°C to +70°C and can handle external light interference up to 3000lux from incandescent lamps and 10000lux from sunlight. The QMR8/0N-0AVE80 is CE approved and EMC compatible, making it a reliable choice for various industrial applications.
