Datasensing QXC/C0-2F Sensors
Datasensing
$198.73
The Datasensing QXC/C0-2F Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a retroreflective design with a 4-meter nominal sensing distance, these sensors are equipped with axial and right-angle optics for versatile application. The sensors boast a fast response time of 0.75-0.5 ms and a high output current of over 300 mA, making them suitable for demanding environments. With NPN-PNP selectable output and a polarized function principle, they offer flexibility in various setups. The sensors are housed in a durable ABS material with an IP65 degree of protection, ensuring resilience against harsh conditions. They are equipped with two LED indicators for threshold and signal margin, providing clear status updates. The sensors operate efficiently within a voltage range of 10 to 30 VDC and feature short-circuit and reverse polarity protection for enhanced safety. With a compact cubic design and M8 plug 4-pin connections, installation is straightforward. The package includes ST70 mounting brackets and screws for easy setup. Ideal for applications requiring long-distance capability and precision beam detection, the Datasensing QXC/C0-2F Sensors are a reliable choice for industrial automation needs.
- Nominal sensing distance:
- 5m
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Polarized
- Optic position:
- Radial 90°
- Output type:
- NPN/PNP Selectable NC
- Output Function:
- NC
- Switching frequency:
- 750Hz
- Response time:
- 666µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 20mA
- Load current:
- ?300mA
- Leakage current:
- ? 100?A @ 30Vdc
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red(output status) , Geen (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Dimensions:
- 15x23x63
- Weight:
- 70g
- Connections:
- M8 plug 4pin
- Active Head Material:
- Acrylic
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Material:
- ABS
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST70 mounting brakets and screws
- Dimensions:
- 15x23x40
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
