Datasensing QXR/C0-2E Sensors

The Datasensing QXR/C0-2E Sensors are advanced photoelectric sensor receivers designed for precision and reliability. Featuring axial and right angle optics, these sensors are equipped with two LEDs for threshold and signal margin indication. They utilize visible red light in retro-reflective, polarized, and through-beam models, ensuring long-distance capability and a precision beam. With a fast response time of 0.75-0.5 ms and NPN-PNP selectable output, these sensors offer high output current exceeding 300 mA. The QXR/C0-2E sensors boast a nominal sensing distance of 8 meters and repeat accuracy of ? 5%. Sensitivity can be adjusted via a trimmer, and the optic position is radial at 90°. The output type is NPN/PNP selectable NC, with a switching frequency of 500Hz and a response time of 1ms. Operating within a voltage range of 10 to 30VDC, these sensors have a no-load supply current of ? 5mA and a load current of ?300mA. They feature a leakage current of ? 100?A at 30Vdc and an output voltage drop of ?1.2V at Iload=100mA. Designed to withstand external light interference up to 3000lux from incandescent lamps and 10000lux, these sensors are housed in durable ABS material with an acrylic active head. They are compact, with dimensions of 15x23x40 mm and a weight of 70g. The sensors are equipped with M12 plug connections and are protected against short-circuits and reverse polarity. They operate efficiently in temperatures ranging from -25°C to +70°C without freezing and are CE approved with EMC compatibility to EN 60947-5-2 standards. The sensors come with ST70 mounting brackets and screws, ensuring easy installation and mechanical protection rated at IP65.
