Datasensing RX6/00-1B Sensors
Datasensing
$141.73
The Datasensing RX6/00-1B Sensors are advanced photoelectric sensors designed for high-performance applications. Featuring a diffuse reflection model with a nominal sensing distance of 1 meter, these sensors are ideal for long-distance detection tasks. The compact design, measuring 26x86.6x61 mm, allows for versatile installation options, supported by axial and right-angle brackets.
Equipped with a multifunctional DECOUT® output, the sensors offer selectable NPN/PNP and NO/NC configurations, ensuring compatibility with various systems. The sensors boast a high switching frequency of 500Hz and a rapid response time of 1ms, making them suitable for fast-paced environments.
The RX6/00-1B Sensors include a trimmer for sensitivity adjustment, allowing precise control over detection capabilities. The LED alignment indicator provides 360° visibility, with red and green LEDs indicating output status and stability, respectively.
Built to withstand challenging conditions, these sensors operate within a temperature range of -25°C to +70°C and feature IP65 mechanical protection. They are resistant to shocks and vibrations, complying with IEC standards, and offer short-circuit and reverse polarity protection.
The sensors are housed in durable PC material with a PMMA active head, ensuring longevity and reliability. They are compatible with M12 plug connections and come with a ST81 mounting bracket and screws for easy installation. With CE and cULus approvals, the Datasensing RX6/00-1B Sensors are a robust choice for industrial applications requiring precise and reliable sensing solutions.
- Nominal sensing distance:
- 1m
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (long distance, >600mm)
- Notes:
- white target Kodak 90% 400 x 400mm EG=1,5
- Optic position:
- Axial
- Output type:
- Decout NPN/PNP Selectable Decout NO/NC Selectable
- Output Function:
- Decout NO/NC Selectable
- Switching frequency:
- 500Hz
- Response time:
- 1ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (output status) o (alineament), Green (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- ? 5000lux (incandescent lamp)
- Weight:
- 90g
- Housing Material:
- PC
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST81 mounting bracket and screws
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
