Datasensing TFM4/1X-0V Sensors

The Datasensing TFM4/1X-0V Sensor is a compact and robust time-of-flight sensor designed for precision and reliability. With a nominal sensing distance of 600mm and a wide-angle divergent spot dimension of 25°, this sensor is ideal for various applications requiring accurate distance measurement. It features a programmable switching frequency ranging from 10 Hz to 80 Hz, allowing for flexible operation. The sensor is equipped with two digital push-pull outputs, offering selectable output types of PNP or Pushpull, and a resolution of 3mm for precise detection. Built to withstand harsh environments, the TFM4/1X-0V boasts an IP67 protection degree, ensuring complete protection against electrical damages and environmental factors. The sensor is completely filled with resin, enhancing its durability and longevity. It operates efficiently within a voltage range of 19.2 to 28.8VDC, with a low no-load supply current of ? 40mA and a load current of ?50mA. The sensor's design includes short-circuit and reverse polarity protection, as well as impulsive overvoltage protection, ensuring reliable performance. The TFM4/1X-0V features LED indicators for easy status monitoring, with green indicating normal operation, red for out-of-range conditions, and yellow for status updates. Its compact dimensions of 13 x 2 x 31.2mm and lightweight housing made of PA66 + ABS make it easy to integrate into various systems. The sensor's active head is made of glass, providing clear and accurate laser infrared emission (class 1) for precise measurements. Operating within a temperature range of -10°C to +50°C and a humidity level of < 80% without condensation, the TFM4/1X-0V is suitable for diverse environments. It complies with CE approvals and EMC compatibility standards (EN 60947-5-2), ensuring high-quality performance and safety. Whether for industrial automation, robotics, or other applications, the Datasensing TFM4/1X-0V Sensor delivers reliable and accurate sensing solutions.
