Leuze AMS 307i 120 Optical distance sensor
Leuze
$6,110.00
The Leuze AMS 307i 120 is an optical distance sensor designed for precise positioning tasks, offering a measurement range up to 120 m with an accuracy of ±2 mm and repeatability of 0.6 mm (3 sigma). It features a maximum traverse rate of 10 m/s, measurement value output in 1.7 ms, and supports a supply voltage of 1830 V DC with current consumption up to 500 mA (with heating). The sensor includes analog output and IO-Link interface for integration in industrial automation, with a compact design suitable for applications in stacker cranes, mobile vehicles, and confined spaces requiring wear-free distance measurement.
Documentation
- Technical Datasheet: https://www.leuze.com/en-us/ams-307i-120/50137594
- Product Overview: https://www.leuze.com/en-us/products/measuring-sensors/optical-distance-sensors
- Operating Instructions: https://www.leuze.com/en-us/support/downloads/operating-instructions/ams-307i
- CAD Data: https://www.leuze.com/en-us/support/downloads/cad-data/ams-307i-120
- Series:
- AMS 300i
- Application:
- Collision protection of cranes / gantry cranes,Positioning of electroplating plants,Positioning of skillet systems and side-tracking skates,Positioning of stacker cranes
- Order guide:
- Reflective tape must be ordered separately
- Light source:
- Laser, Red
- Laser class:
- 2, IEC/EN 60825-1:2014
- Light spot size [at sensor distance]:
- 100 mm [120,000 mm]
- Measurement value calculation time:
- 8 ms
- Measurement range:
- 200 ... 120,000 mm
- Resolution:
- 0.001 ... 10 mm
- Accuracy:
- 2 mm
- Reproducibility (3 sigma):
- 0.9 mm
- Measurement value output:
- 1.7 ms
- Max. traverse rate:
- 10 m/s
- Supply voltage UB:
- 18 ... 30 V, DC
- Type:
- SSI
- Clock frequency:
- 50 ... 800 kHz
- Designation on device:
- PWR
- Material:
- Metal
- Function:
- Data interface
- Designation on device:
- SSI
- Type:
- Male
- Encoding:
- B-coded
- Function:
- Service interface
- Designation on device:
- SERVICE
- Type:
- Female
- Encoding:
- A-coded
- Dimension (W x H x L):
- 84 mm x 166.5 mm x 159 mm
- Housing material:
- Metal
- Metal housing:
- Diecast zinc/aluminum
- Lens cover material:
- Glass
- Net weight:
- 2,450 g
- Operational controls:
- Membrane keyboard
- Ambient temperature, operation:
- -5 ... 50 °C
- Ambient temperature, storage:
- -30 ... 70 °C
- Relative humidity (non-condensing):
- 90 %
- Degree of protection:
- IP 65
- Protection class:
- III
- Approvals:
- c UL US
- Customs tariff number:
- 90318020
- ECLASS 5.1.4:
- 27270801
- ECLASS 8.0:
- 27270801
- ECLASS 9.0:
- 27270801
- ECLASS 10.0:
- 27270801
- ECLASS 11.0:
- 27270801
- ECLASS 12.0:
- 27270916
- ECLASS 13.0:
- 27270916
- ECLASS 14.0:
- 27270916
- ECLASS 15.0:
- 27270916
- ETIM 5.0:
- EC001825
- ETIM 6.0:
- EC001825
- ETIM 7.0:
- EC001825
- ETIM 8.0:
- EC001825
- ETIM 9.0:
- EC001825
- ETIM 10.0:
- EC001825
- Datasheet:
- View
- Brochure:
- View
- Declaration of Conformity:
- View
