Description
Technical Data
Input
Rated voltage UN
DC 12/24/48 V
Rated current IN
max. DC 40 A
Reverse voltage protection
No
Connection type input
- Spring terminal
- 0.33 mm2 ??? 16.0 mm2
- AWG 22 ??? AWG 6
Conductor connection cross section
- single-wire: max. 16 mm2
- finely stranded: max 10 mm2
- finely stranded with AEH: max 10 mm2
Output
Rated voltage UN
DC 12/24/48 V
Connection type output
screwless contact slide
Copper bus bar
3 ?? 10mm
Output current
max. DC 40 A
General
Operation temperature range
-25 ???C ??? +50 ???C
Storage temperature range
-40???C???85???C
Dimensions (w ?? h ?? d)
10??119,4??63,7 mm
Housing material
PA 6.6 (UL 94 V-0, NFF I2, F2)
Mounting
- DIN rail mountable TS35
- (EN 60715)
Protection class
IP20
Installation position
any
Strip length
12 mm
Weight
0,045 kg/piece
Approvals
cULus (E135145)
PU
1 piece
Dimensions
