Schneider Electric EJB14040EPD Miniature Circuit Breaker 277V 40A
Schneider Electric
$1,409.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 40A, 1 pole, and has an operating voltage of 277 VAC. It also provides a 100 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This one includes 30 mA ground protection. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
- Awg Gauge:
- AWG 14...AWG 6 copper || AWG 12...AWG 4 aluminium
- Product Certifications:
- cULus
- Earth-Leakage Sensitivity:
- 30 mA
- Number Of Spaces:
- 2
- Electrical Connection:
- lugs aluminium
- Line Rated Current:
- 40 A
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Protection Type:
- short-circuit || overload
- Holding Current:
- 630 A
- Number Of Spaces Required:
- 2
- Breaking Capacity Code:
- J
- Circuit Breaker Application:
- HACR rated || HID rated
- Module Type:
- E-Frame
- Breaking Capacity:
- 65 kA 240 V AC || 65 kA 277 V AC || 100 kA 120 V AC || 65 kA 120/240 V AC
- Height:
- 6.64 in
- Rohs Exemption Information:
- Yes
- Trip Unit Rating:
- 1800-1800 A
- Tightening Torque:
- 3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
- Net Weight:
- 2 lb(US)
- Ambient Air Temperature For Operation:
- 40 °C
- Product Or Component Type:
- miniature circuit-breaker
- Mercury Free:
- Yes
- Earth-Leakage Protection Class:
- class B
- Number Of Poles:
- 1
- Width:
- 1.96 in
- Mounting Mode:
- bolt-on
- Range Of Product:
- 125 A Frame EDB-EGB-EJB
- Depth:
- 4.05 in
- [Ue] Rated Operational Voltage:
- 277 V AC
- Warranty:
- 18 months
- Local Signalling:
- trip indicator
- Device Short Name:
- EJB
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Product Destination:
- NF panelboard
- Trip Unit Technology:
- thermal-magnetic
