Schneider Electric EJB14045 Miniature Circuit Breaker 277V 45A

(No reviews yet) Write a Review

Write a Review

Schneider Electric EJB14045 Miniature Circuit Breaker 277V 45A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

EJB14045

UPC:

785901130550

MPN:

Condition:

New

Protection Type:

short-circuit || overload

Mercury Free:

Yes

Range Of Product:

125 A Frame EDB-EGB-EJB

Ambient Air Temperature For Operation:

40 °C

Holding Current:

630 A

Depth:

4.05 in

Awg Gauge:

AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper

Product Or Component Type:

miniature circuit-breaker

Trip Unit Technology:

thermal-magnetic

Breaking Capacity:

65 kA 240 V AC || 65 kA 277 V AC || 100 kA 120 V AC || 65 kA 120/240 V AC

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Number Of Poles:

1

Circuit Breaker Application:

HID rated || HACR rated

Module Type:

E-Frame

[Ue] Rated Operational Voltage:

277 V AC

Height:

5.66 in

Width:

0.98 in

Electrical Connection:

lugs aluminium

Mounting Mode:

bolt-on

Number Of Spaces:

1

Warranty:

18 months

Rohs Exemption Information:

Yes

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Breaking Capacity Code:

J

Net Weight:

2 lb(US)

Product Certifications:

cULus

Trip Unit Rating:

1800-1800 A

Line Rated Current:

45 A

Local Signalling:

trip indicator

Number Of Spaces Required:

1

Device Short Name:

EJB

Tightening Torque:

3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)

Product Destination:

NF panelboard
