Schneider Electric HGA260501 Molded Case Circuit Breaker 600V 50A

Schneider Electric HGA260501 Molded Case Circuit Breaker 600V 50A

Schneider Electric
SKU:
HGA260501
|
UPC:
785901651512
Availability:
Contact us to confirm availability and lead times.
$1,338.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 50A, 2 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an AB phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Mounting Height:
3 in
Communication Interface:
Modbus || Ethernet
Suitability For Isolation:
yes IEC 60947-2
Magnetic Hold Current:
400 A
Mounting Mode:
I-Line bracket)
Ip Degree Of Protection:
front cover IP40 IEC 60529
Pvc Free:
Yes
Mounting Support:
bracket
Magnetic Tripping Current:
850-850 A
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Ambient Air Temperature For Operation:
-2-70 °C
Breaking Capacity:
65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489
Color:
Black
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Width:
104 mm
Terminal Identifier:
AL150HD
Mercury Free:
Yes
Circularity Profile:
ENVEOLI1311006EN
Product Certifications:
UL || CSA || NOM
Eu Rohs Directive:
Compliant
Ambient Air Temperature For Storage:
-50-85 °C
Poles Description:
2P
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Circuit Breaker Application:
HACR rated
Wire Stripping Length:
16 mm
Quality Labels:
CE
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Warranty:
18 months
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Net Weight:
2.2 kg
Continuous Current Rating:
0.8
Device Application:
distribution
Depth:
86 mm
Electrical Connection:
I-Line connection, line || lugs, load
Trip Unit Technology:
thermal-magnetic
Rohs Exemption Information:
Yes
Network Frequency:
50/60 Hz
Product Or Component Type:
circuit breaker
Pollution Degree:
3 IEC 60947-1
Control Type:
toggle
Product Name:
PowerPact H
Height:
163 mm
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Line Rated Current:
50-50 A
Utilisation Category:
category A
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Local Signalling:
switched off (OFF) 1 trip indicator green)
Sustainable Offer Status:
Green Premium product
Quantity Per Set:
1
Phase Connection:
AB
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Breaking Capacity Code:
G
Environmental Disclosure:
ENVPEP1311006EN
Protected Poles Description:
2t
Range:
PowerPact
