Schneider Electric HLL26030 Molded Case Circuit Breaker 600V 30A

Schneider Electric HLL26030 Molded Case Circuit Breaker 600V 30A

Schneider Electric
SKU:
HLL26030
|
UPC:
785901659181
Availability:
Contact us to confirm availability and lead times.
$3,546.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 50kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 30A, 2 pole, circuit breaker has a breaking capacity of 50kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Breaking Capacity:
125 kA 240 V AC 50/60 Hz UL 489 || 100 kA 480 V AC 50/60 Hz UL 489 || 50 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 50 kA 500 V DC UL 489
Breaking Capacity Code:
L
Color:
Black
Ambient Air Temperature For Operation:
-2-70 °C
Suitability For Isolation:
yes IEC 60947-2
Communication Interface:
Modbus || Ethernet
Rohs Exemption Information:
Yes
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Magnetic Hold Current:
350 A
Mounting Mode:
unit mount lug)
Width:
104 mm
Local Signalling:
switched off (OFF) 1 trip indicator green)
Utilisation Category:
category A
Warranty:
18 months
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Ambient Air Temperature For Storage:
-50-85 °C
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Mercury Free:
Yes
Product Or Component Type:
circuit breaker
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Ip Degree Of Protection:
front cover IP40 IEC 60529
Height:
163 mm
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Network Frequency:
50/60 Hz
Trip Unit Technology:
thermal-magnetic
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
[Ics] Rated Service Breaking Capacity:
125 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 100 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 50 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Quantity Per Set:
1
Mounting Support:
lug
Electrical Connection:
lugs, line || lugs, load
Wire Stripping Length:
16 mm
Terminal Identifier:
AL150HD
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Depth:
86 mm
Product Certifications:
UL || CSA || NOM
Line Rated Current:
30-30 A
Circuit Breaker Application:
HACR rated
Protected Poles Description:
2t
Magnetic Tripping Current:
750-750 A
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Pollution Degree:
3 IEC 60947-1
Product Name:
PowerPact H
Quality Labels:
CE
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Pvc Free:
Yes
Eu Rohs Directive:
Compliant with Exemptions
Environmental Disclosure:
ENVPEP2206027EN
Net Weight:
2.2 kg
Range:
PowerPact
Circularity Profile:
ENVEOLI2206027EN
Sustainable Offer Status:
Green Premium product
Control Type:
toggle
Device Application:
distribution
Poles Description:
2P
Continuous Current Rating:
0.8
