Schneider Electric HLL36080LV Circuit breaker, PowerPacT H, 80A, 3 pole, 600VAC, 50kA, lugs, thermal magnetic, 80%, control wire OFF end

Schneider Electric HLL36080LV Circuit breaker, PowerPacT H, 80A, 3 pole, 600VAC, 50kA, lugs, thermal magnetic, 80%, control wire OFF end

Schneider Electric
SKU:
HLL36080LV
$4,803.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 50kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 80A, 3 pole, circuit breaker has a breaking capacity of 50kA at 600VAC. This circuit breaker has a continuous current rating of 80%. This unit includes a control wire terminal on the load end. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Environmental Disclosure:
ENVPEP2206027EN
Wire Stripping Length:
16 mm
Pvc Free:
Yes
Accessory / Separate Part Type:
control wire OFF end
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Circularity Profile:
ENVEOLI2206027EN
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Product Name:
PowerPact H
Pollution Degree:
3 IEC 60947-1
Mercury Free:
Yes
Electrical Connection:
lugs, line || lugs, load
Continuous Current Rating:
0.8
Ambient Air Temperature For Operation:
-25-70°C
Depth:
86 mm
Net Weight:
2.2 kg
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Color:
Black
Trip Unit Technology:
thermal-magnetic
Sustainable Offer Status:
Green Premium product
Communication Interface:
Modbus || Ethernet
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Terminal Identifier:
AL150HD
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Warranty:
18 months
Weight:
2.2 kg
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Poles Description:
3P
Quantity Per Set:
1
Eu Rohs Directive:
Compliant with Exemptions
Ip Degree Of Protection:
front cover IP40 IEC 60529
Mounting Support:
lug
Breaking Capacity Code:
L
Suitability For Isolation:
yes IEC 60947-2
Magnetic Hold Current:
800 A
Line Rated Current:
80-80 A
Length:
16 mm
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Magnetic Tripping Current:
1450-1450 A
Mounting Mode:
unit mount lug)
Device Application:
distribution
Country of Origin:
United States
Product Certifications:
UL || CSA || NOM
Utilisation Category:
category A
Ambient Air Temperature For Storage:
-50-85°C
Quality Labels:
CE
Network Frequency:
50/60 Hz
