Schneider Electric LC1G2254LSEA Contactor, high power, TeSys Giga, advanced version, 4 pole/NO, AC-1 <=440V 330A, 200-500VAC/DC coil

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric LC1G2254LSEA Contactor, high power, TeSys Giga, advanced version, 4 pole/NO, AC-1 <=440V 330A, 200-500VAC/DC coil

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

LC1G2254LSEA

UPC:

MPN:

LC1G2254LSEA

Condition:

New

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Overvoltage Category:

III

Range:

TeSys

[Ith] Conventional Free Air Thermal Current:

330 A (at 40°C)

Associated Fuse Rating:

250 A aM at <= 440 V for motor || 200 A aM at <= 690 V for motor || 400 A gG at <= 690 V

Coil Technology:

built-in bidirectional peak limiting

[Uc] Control Circuit Voltage:

200...500 V AC 50/60 Hz || 200...500 V DC

Mercury Free:

Yes

California Proposition 65:

WARNING: This product can expose you to chemicals including: Styrene, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For m

[Icw] Rated Short-Time Withstand Current:

1.8 kA - 10 s || 1.0 kA - 30 s || 0.85 kA - 1 min || 0.56 kA - 3 min || 0.44 kA - 10 min

Height:

255 mm

Sustainable Offer Status:

Green Premium product

Eu Rohs Directive:

Compliant with Exemptions

[Uimp] Rated Impulse Withstand Voltage:

8 kV

Auxiliary Contact Composition:

1 NO + 1 NC

Safety Reliability Level:

B10d = 400000 cycles contactor with nominal load EN/ISO 13849-1 || B10d = 3000000 cycles contactor with mechanical load EN/ISO 13849-1

Irms Rated Making Capacity:

2720 A at 440 V

Poles Description:

4P

Average Impedance:

0.00015 Ohm

Inrush Power In W:

215 W

Standards:

EN/IEC 60947-4-1 || EN/IEC 60947-5-1 || UL 60947-4-1 || CSA C22.2 No 60947-4-1 || JIS C8201-4-1 || JIS C8201-5-1 || UL 60335-1 || UL 60335-2-40:Annex JJ

[Ui] Rated Insulation Voltage:

1000 V

Ambient Air Temperature For Storage:

-60-80°C

Mechanical Robustness:

vibrations 5-300 Hz 2 gn contactor open || vibrations 5-300 Hz 4 gn contactor closed || shocks 10 gn 11 ms contactor open || shocks 15 gn 11 ms contactor closed

Pvc Free:

Yes

Net Weight:

5.1 kg

Weight:

5.1 kg

Control Circuit Voltage Limits:

operational: 0.8 Uc Min...1.1 Uc Max (at <60°C) || drop-out: 0.1 Uc Max...0.45 Uc Min (at <60°C)

Tightening Torque:

18 N.m

Circularity Profile:

ENVEOLI2105013

Protective Treatment:

TH

Ambient Air Temperature For Operation:

-25-60°C

China Rohs Regulation:

X

Mounting Support:

plate

Color:

dark grey

Ip Degree Of Protection:

IP2X front face with shrouds IEC 60529 || IP2X front face with shrouds VDE 0106

Environmental Disclosure:

ENVPEP2105013

Product Or Component Type:

contactor

[Ue] Rated Operational Voltage:

<= 1000 V AC 50/60 Hz || <= 460 V DC

Rated Breaking Capacity:

2050 A at 440 V

Pole Contact Composition:

4 NO

Mechanical Durability:

8 Mcycles

Operating Time:

40...70 ms closing || 15...50 ms opening

Inrush Power In Va:

295-295 VA

Rohs Exemption Information:

Yes

Compatibility Code:

LC1G

Country of Origin:

China

Permissible Ambient Air Temperature Around The Device:

-40-70°C at Uc
