Schneider Electric LHL26300 Molded Case Circuit Breaker 600V 300A

Schneider Electric LHL26300 Molded Case Circuit Breaker 600V 300A

Schneider Electric
SKU:
LHL26300
|
UPC:
785901358633
Availability:
Contact us to confirm availability and lead times.
$9,543.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
Square D LH molded case circuit breakers provide thermal magnetic protection. Their primary function is automatic opening of a circuit under overload or short circuit conditions or manual opening. LH circuit breakers contain thermal (overload) and magnetic (short circuit) sensing elements in each pole. Push-to-Trip allows the circuit breaker to be manually tripped without exposure to live parts. This Square D LH molded case circuit breaker is a 2 pole unit mount breaker, 300A and 600VAC. The thermal magnetic circuit breaker has an interrupting rating of 25kA for 600VAC and 50kA for 250VDC. LH breakers are UL 489, CSA, IEC certified.
Additional Information
Mounting Mode:
unit mount
Electrical Connection:
lugs, load || lugs, line
Magnetic Tripping Current:
3000-3000 A
Line Rated Current:
300 A
Eu Rohs Directive:
Compliant with Exemptions
Mercury Free:
Yes
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Width:
6 in
Magnetic Hold Current:
1500 A
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Trip Unit Technology:
thermal-magnetic
Poles Description:
2P
Product Or Component Type:
circuit breaker
Breaking Capacity Code:
H
Product Certifications:
IEC || UL Listed || CSA
Circularity Profile:
N/A
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Depth:
5.84 in
Pvc Free:
Yes
Environmental Disclosure:
ENVPEP1410004EN
Terminal Identifier:
AL400LA
Circuit Breaker Application:
HACR rated
Tightening Torque:
13-13 N.m 42-304 mm² (AWG 1...600 kcmil) || 13-13 N.m 42-127 mm² (AWG 1...250 kcmil)
Height:
11 in
Halogen Content Performance:
Halogen free plastic parts product
Warranty:
18 months
Rohs Exemption Information:
Yes
Sustainable Offer Status:
Green Premium product
