Schneider Electric LUFN11 Auxiliary Contact Mod 1No 1Nc

Schneider Electric LUFN11 Auxiliary Contact Mod 1No 1Nc

Schneider Electric
SKU:
LUFN11
|
UPC:
3389110365177
Availability:
Contact us to confirm availability and lead times.
$34.50
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
TeSys U auxiliary signaling contacts module to be inserted in standard power bases LUB12, LUB32, LUB38 or advanced power base LUB120, LUB320, LUB380. It indicates the ON/OFF running status of the motor, whatever the direction of rotation. It provides 1NO+1NC instantaneous auxiliary contacts rated 24-250V AC/DC 5A max. It is powered by the control unit. To be inserted in the cavity of a power base provided for the auxiliary modules. Certified when used in conjunction with a LUB power base (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
Additional Information
Range:
TeSys
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Auxiliary Contact Composition:
1 NO + 1 NC
Mercury Free:
Yes
Device Short Name:
LUFN
Eu Rohs Directive:
Compliant
Rohs Exemption Information:
Yes
Reach Regulation:
Free of Substances of Very High Concern above the threshold
[Ui] Rated Insulation Voltage:
250 V CSA || 250 V IEC 60947-5-1 || 250 V UL
China Rohs Regulation:
X
Sustainable Offer Status:
Green Premium product
Minimum Switching Voltage:
17 V
[Ue] Rated Operational Voltage:
<= 250 V AC || <= 250 V DC
Environmental Disclosure:
ENVPEP111254EN
Reach Free Of Svhc:
Yes
Net Weight:
0.05 kg
Warranty:
18 months
Minimum Switching Current:
5 mA
Product Or Component Type:
auxiliary contact
Circularity Profile:
N/A
Toxic Heavy Metal Free:
Yes
[Ith] Conventional Free Air Thermal Current:
0.208333333333333
Catalog:
View
Datasheet:
View
