Schneider Electric LX1G3REHEN Control module,TeSys Giga,48-130V AC/DC,for LC1G265-330/3P standard version

(No reviews yet) Write a Review
SKU:
LX1G3REHEN
MPN:
LX1G3REHEN
Condition:
New
China Rohs Regulation:
X
[Uc] Control Circuit Voltage:
48...130 V AC/DC 50/60 Hz
Mercury Free:
Yes
Coil Technology:
built-in bidirectional peak limiting
Ambient Air Temperature For Storage:
-60-80°C
Inrush Power In W:
695.0 W DC
Control Circuit Voltage Limits:
operational 0.8...1.1 Uc 60°C) || drop-out 0...0.45 Uc 60°C)
Environmental Disclosure:
ENVPEP2105013
Eu Rohs Directive:
Compliant with Exemptions
Device Short Name:
LX1G
Pollution Degree:
3 IEC 60947-1
Permissible Ambient Air Temperature Around The Device:
-40-70°C at Uc
Mechanical Durability:
5 Mcycles
Connections - Terminals:
control circuit push-in termination 1 0.2-2.5 mm² solid stranded without cable end sleeve AWG 26...AWG 12 || control circuit push-in termination 1 0.25-2.5 mm² flexible with cable end sleeve AWG 24...AWG 14 || control circuit push-in termination 2
Inrush Power In Va:
965-965 VA 120 V AC, 60 Hz
Product Compatibility:
LC1G265...330
Hold-In Power Consumption In W:
4.5-4.5 W DC
Quantity Per Set:
1
Range:
TeSys
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Sustainable Offer Status:
Green Premium product
Operating Time:
20...35 ms opening || 40...55 ms closing
Maximum Operating Rate:
600 cyc/mn 60°C
Halogen Content Performance:
Halogen free plastic parts product
Electromagnetic Compatibility:
EMC immunity conforming to IEC 60947-4-1 || emission tests criteria A conforming to IEC 60947-4-1 || immunity to radiated radio-electrical interference - test level: 20 V/m conforming to EN/IEC 61000-4-3 || voltage dips and interruptions immunity tes
Operating Altitude:
9842.52 ft (3000 m) without derating || 5000 m with derating factor
Range Compatibility:
TeSys G LX1G contactor coil
Product Or Component Type:
contactor coil
Depth:
93.0 mm
Hold-In Power Consumption In Va:
16-16 VA 120 V AC, 60 Hz
Ip Degree Of Protection:
IP20 IEC 60529
Standards:
EN/IEC 60947-4-1 || UL 60947-4-1A || CSA C22.2 No 60947-4-1
Country of Origin:
China
California Proposition 65:
WARNING: This product can expose you to chemicals including: Styrene, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For m
Ambient Air Temperature For Operation:
-25-60°C
Poles Description:
3P
Circularity Profile:
ENVEOLI2105013
Pvc Free:
Yes
Rohs Exemption Information:
Yes
$235.00

Description

It is a 48-130V AC/DC control module for 3 poles TeSys Giga 265-300 contactor (advanced version). Coil designed for less energy consumption and wider voltage band-width, connection by spring terminal. It allows contactor operation with high AC-3 operating rates until 600 cycles/hour and environments until 60°C. Control module has connectors for connecting the coil control A1, A2 circuit, pole status and diagnostic signaling circuits. Local Contact Wear Diagnosis (CWD) as standard function, continuous monitoring with healthy and alarm indicators. It provides IP2x protection in Front face with shrouds conforming to IEC 60529 and VDE 0106. It is accessible from the front and maintained with very low down times. Unique QR code provides quick access to complete product data.
