Schneider Electric NSYCGX16H Cable Gland S.Steel 316L+Nut M16

SKU:

NSYCGX16H

UPC:

3.60648E+12

MPN:

Condition:

New

Material:

seal CR (chloroprene) || body stainless steel AISI 316L

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Net Weight:

0.017 kg

Color:

Gray

Product Or Component Type:

cable gland

Rohs Exemption Information:

Yes

Fixing Mode:

screwed || by nut

Range Compatibility:

Spacial Spacial CRN || Spacial Spacial S3D || Spacial Spacial S3X

Product Certifications:

VDE

Ambient Air Temperature For Operation:

-20-100 °C permanent || -40-150 °C intermittent

Mercury Free:

Yes

Mounting Location:

enclosure bottom || enclosure top

China Rohs Regulation:

Pro-active China RoHS declaration (out of China RoHS legal scope)

Toxic Heavy Metal Free:

Yes

Reach Free Of Svhc:

Yes

Ip Degree Of Protection:

IP68 IEC 60529 5 bar, 30 min

Range:

Spacial

Quantity Per Set:

set of 5

Height:

30 mm

Flame Retardance:

V2 conforming to UL 94

Device Composition:

1 cable gland || 1 lock nut || 1 seal

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Cable Entry:

cable gland M16

Accessory / Separate Part Category:

cable management accessory
