Schneider Electric NSYCR150WU2C Resist.Heat.Insul.150W,110-250V

(No reviews yet) Write a Review

Write a Review

Schneider Electric NSYCR150WU2C Resist.Heat.Insul.150W,110-250V

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

NSYCR150WU2C

UPC:

3606480152351

MPN:

Condition:

New

Input Voltage:

110...250 V AC 50/60 Hz

Fixing Mode:

by clips

Material:

body extruded aluminium || Cover plastic

Circularity Profile:

N/A

Ambient Air Temperature For Operation:

-40-70 °C

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Environmental Disclosure:

ENVPEP2103011EN

Product Certifications:

VDE || UL

Depth:

external 90 mm

Operating Position:

vertical

Ip Degree Of Protection:

IP20

Warranty:

18 months

Electrical Connection:

4 screw terminals 2.5 mm²

Electrical Insulation Class:

class II

Eu Rohs Directive:

Compliant with Exemptions

Range:

ClimaSys

Mercury Free:

Yes

Power Range:

150 W

Product Name:

ClimaSys CR

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Condition Of Use:

electrical protection is needed || heaters must be installed with a thermal controller || air sealed enclosure

Product Or Component Type:

resistance heater

Height:

external 150 mm

Sustainable Offer Status:

Green Premium product

Rohs Exemption Information:

Yes

Width:

external 60 mm

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Mounting Support:

35 mm DIN rail

Catalog:

View

Datasheet:

View
