Schneider Electric NSYCRN64150 Crn 600X400X150 One Plain Door
Schneider Electric
$140.88
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric NSYCRN64150 Crn 600X400X150 One Plain Door
The Spacial CRN wall-mounting compact enclosure comes in grey colour and designed for multi-purpose application. This compact enclosure is composed of body, cable gland plate, door, lock. The compact enclosure is made of steel (body), making it durable and resistant. It has IP66 and IK10 protection level, which can help protect against impact, water and dust. The dimensions are (W) 400 mm x (H) 600 mm x (D) 150 mm. It features a back welded with double profile forming a protected sealed area, sides made from a single folded section. The door type is plain, it has 1 door(s) and the door opening side is reversible. Equipped with a 3 mm double-bar lock lock type. Featuring a epoxy-polyester powder surface finish, which ensures a bright, even and inviting finish. This device is qualified as a green premium product, with minimal use of hazardous substances. This compact enclosure is c.UL certified.
- Sustainable Offer Status:
- Green Premium product
- Accessibility For Operation:
- front
- Warranty:
- 18 months
- Type Of Gland Plate:
- standard
- Net Weight:
- 8.45 kg
- Rohs Exemption Information:
- Yes
- Color:
- Gray RAL 7035)
- Installation Accessory Type:
- wall-mounting
- Removable Parts:
- door by hinges || cable gland plate by screws
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Mercury Free:
- Yes
- Number Of Doors:
- front face 1
- Door Opening Side:
- reversible 120 °)
- Surface Finish:
- epoxy-polyester powder
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Environmental Disclosure:
- ENVPEP100104EN
- Device Application:
- multi-purpose
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Device Composition:
- 1 body || 1 cable gland plate || 1 door || 1 lock
- Product Name:
- Spacial CRN
- Enclosure Nominal Width:
- 400 mm
- Door Type:
- Solid
- Standards:
- IEC 62208
- Variant Particularity:
- sides made from a single folded section || back welded with double profile forming a protected sealed area
- Ip Degree Of Protection:
- IP66 IEC 60529
- Material:
- body steel
- Range:
- Spacial
- Enclosure Nominal Depth:
- 150 mm
- Circularity Profile:
- N/A
- Enclosure Nominal Height:
- 600 mm
- Ik Degree Of Protection:
- IK10 IEC 62262
- Lock Type:
- 3 mm double-bar lock
- Mounting Plate Description:
- without mounting plate
- Product Certifications:
- cUL || UL || DNV-GL
- Product Or Component Type:
- compact enclosure
- Brochure:
- View
- Datasheet:
- View
