Schneider Electric

Schneider Electric NSYFPLS2754G 7035 Poly. Pls Body 27X54X13.5

SKU:

NSYFPLS2754G

UPC:

3.60648E+12

MPN:

Condition:

New

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Product Certifications:

UL

Sustainable Offer Status:

Green Premium product

Device Composition:

1 rear part on enclosure

Environmental Disclosure:

ENVPEP110704EN

Rohs Exemption Information:

Yes

Electrical Insulation Class:

class II

Enclosure Nominal Width:

540 mm

Enclosure Nominal Height:

270 mm

Product Or Component Type:

insulating modular rear

Device Short Name:

PLS

Standards:

IEC 62208 || NEMA classification 13 || NEMA 4X

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Color:

body Gray RAL 7035)

Ambient Air Temperature For Storage:

-30-70 °C

Mercury Free:

Yes

Fire Resistance:

960 °C IEC 62208

Range:

Thalassa

Enclosure Nominal Depth:

135 mm

Circularity Profile:

N/A

Ip Degree Of Protection:

IP66 IEC 60529

Material:

polyester reinforced with fibreglass

Device Application:

multi-purpose

Enclosure Mounting:

wall mounted

Ik Degree Of Protection:

IK09 IEC 62262

Product Name:

Thalassa PLS

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Body Type:

one piece moulded

Type Of Front Cover:

without

Datasheet:

View
