Schneider Electric NSYMF1010 Microperf Mount Plate1000X1000

(No reviews yet) Write a Review

Write a Review

Schneider Electric NSYMF1010 Microperf Mount Plate1000X1000

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

NSYMF1010

UPC:

3606480182976

MPN:

Condition:

New

Range:

Spacial

Environmental Disclosure:

ENVPEP2202003EN

Reach Free Of Svhc:

Yes

Warranty:

18 months

Mounting Location:

direct fixing on backstuds || step slide

Mounting Plate Description:

microperforated

Enclosure Nominal Dimensions:

H: 1000 mm W: 1000 mm

Rohs Exemption Information:

Yes

Quantity Per Set:

set of 1

Material:

galvanised steel

Accessory / Separate Part Category:

mounting accessory

Toxic Heavy Metal Free:

Yes

Device Application:

multi-purpose

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Height:

950 mm

Thickness:

2.5 mm

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Fixing Mode:

screwed on backstuds M8 || by fixing element

Width:

950 mm

Sustainable Offer Status:

Green Premium product

Circularity Profile:

N/A

China Rohs Regulation:

Pro-active China RoHS declaration (out of China RoHS legal scope)

Maximum Load:

250 kg S3D, CRN, S3X enclosures || 150 kg PLM enclosure

Range Compatibility:

Spacial Spacial S3D || Spacial Spacial CRN || Spacial Spacial S3X || Thalassa Thalassa PLM

Mercury Free:

Yes

Permanent Permissible Load:

225.6 kg S3D, CRN, S3X enclosures || 135.4 kg PLM enclosure

Net Weight:

17.826 kg

Surface And Useful Surface:

90.3 dm²

Product Or Component Type:

mounting plate

Datasheet:

View
