Schneider Electric NSYMM32 Plain Mount. Plate 300X200

Schneider Electric NSYMM32 Plain Mount. Plate 300X200

Schneider Electric
SKU:
NSYMM32
|
UPC:
3606480183294
Availability:
Contact us to confirm availability and lead times.
$7.70
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
Plain mounting plate for Spacial CRN, S3D, S3X, PLM. For enclosures H is300 x W is200 mm. Multi-purpose mounting accessory. Step slide mounting location or direct fixing on backstuds (M8 screws). 60 Kg permissible load. Galvanised steel. Set of 1.
Additional Information
Warranty:
18 months
Fixing Mode:
screwed on backstuds M8 || by fixing element
Thickness:
1.8 mm
China Rohs Regulation:
Pro-active China RoHS declaration (out of China RoHS legal scope)
Enclosure Nominal Dimensions:
H: 300 mm W: 200 mm
Product Or Component Type:
mounting plate
Toxic Heavy Metal Free:
Yes
Permanent Permissible Load:
60 kg
Quantity Per Set:
set of 1
Sustainable Offer Status:
Green Premium product
Mounting Location:
direct fixing on backstuds || step slide
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Mercury Free:
Yes
Range:
Spacial
Mounting Plate Description:
plain
Circularity Profile:
N/A
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Reach Free Of Svhc:
Yes
Device Application:
multi-purpose
Material:
galvanised steel
Environmental Disclosure:
ENVPEP2202003EN
Width:
150 mm
Net Weight:
0.52 kg
Range Compatibility:
Spacial Spacial S3D || Spacial Spacial CRN || Spacial Spacial S3X || Thalassa Thalassa PLM
Height:
250 mm
Accessory / Separate Part Category:
mounting accessory
Rohs Exemption Information:
Yes
Brochure:
View
Catalog:
View
Datasheet:
View
QN-QUOTE-REQUEST:
true
