Schneider Electric NSYPLAZ1074G 7035 Fs Pol Plinth 1000X750X420

(No reviews yet) Write a Review

Write a Review

Schneider Electric NSYPLAZ1074G 7035 Fs Pol Plinth 1000X750X420

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

NSYPLAZ1074G

UPC:

3.60648E+12

MPN:

Condition:

New

Fire Resistance:

960 °C IEC 62208

Ambient Air Temperature For Storage:

-35-90 °C

Material:

polyester reinforced with fibreglass

Door Type:

Solid front

Mercury Free:

Yes

Enclosure Nominal Width:

750 mm

Rohs Exemption Information:

Yes

Ip Degree Of Protection:

IP54 IEC 60529 plinth type open bottom)

Enclosure Nominal Depth:

420 mm

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Standards:

IEC 62208

Product Certifications:

Veritas

Device Short Name:

PLAZ

Enclosure Nominal Height:

1000 mm

Device Application:

multi-purpose

Lock Type:

4 points lock, handle with 5 mm double bar insert

Accessibility For Operation:

front || rear || bottom

Color:

Gray RAL 7035)

Enclosure Mounting:

floor-standing

Electrical Insulation Class:

class II

Environmental Disclosure:

ENVPEP110505EN

Product Or Component Type:

suitable enclosure

Product Name:

Thalassa PLA

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Removable Parts:

door by hinges || rear panel by fixing element

Body Type:

sealed top and open bottom part assembled with side parts

Sustainable Offer Status:

Green Premium product

Range:

Thalassa

Ik Degree Of Protection:

IK10 IEC 62262 plain door)

Circularity Profile:

N/A

Door Opening Side:

reversible 120 °)

Device Composition:

1 top part || 1 bottom part || 2 side part || 1 rear panel || 1 door || 1 plinth

Number Of Doors:

1
