Schneider Electric NSYRSWC36 19P Swing Rack Center 36U

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric NSYRSWC36 19P Swing Rack Center 36U

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

NSYRSWC36

UPC:

3606480067259

MPN:

Condition:

New

Range:

Spacial

Height:

1800 mm

Mercury Free:

Yes

Accessory / Separate Part Category:

mounting accessory

Lock Type:

handle with ball lock

Fixing Mode:

by fixing element

Width:

800 mm

Permanent Permissible Load:

3.75 kg per unit with a maximum of 150 kg

Sustainable Offer Status:

Green Premium product

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Device Composition:

fixing elements || 2 800 mm swing rack supports || 1 19" swing rack || 2 side plates with ball-lock handle

Enclosure Nominal Dimensions:

H: 1800 mm

Device Application:

electronic application

Rohs Exemption Information:

Yes

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Environmental Disclosure:

ENVPEP110923EN

Depth:

1701 mm

Warranty:

18 months

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Product Or Component Type:

19" rack

Circularity Profile:

N/A

Quantity Per Set:

set of 1

Mounting Location:

on structure of enclosure

Rack Type:

swing centred

Material:

steel

Color:

side plate Gray RAL 7035)

Range Compatibility:

Spacial Spacial SF || Spacial Spacial SM

Opening Of The 19" Racks:

reversible 120 °

Number Of Units 19":

36

Adjustment:

adjustable in depth every 25 mm

Surface Finish:

zinc coated
