Schneider Electric

Schneider Electric NSYSUCR90100 2 Universal Rails 3 Rows 1000

SKU:

NSYSUCR90100

UPC:

3.60649E+12

MPN:

Condition:

New

Mounting Location:

between cross rails || on structure of enclosure

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Material:

steel

Rohs Exemption Information:

Yes

Mercury Free:

Yes

Maximum Load:

70 kg

Thickness:

1.5 mm

Range:

Spacial

Height:

nominal 1000 mm || useful 907 mm

Device Application:

multi-purpose

Sustainable Offer Status:

Green Premium product

Depth:

27 mm

Toxic Heavy Metal Free:

Yes

Enclosure Nominal Dimensions:

H: 100 mm

Range Compatibility:

Spacial Spacial SF || Spacial Spacial SM || Spacial Spacial SFX || Spacial Spacial SMX

Warranty:

18 months

Accessory / Separate Part Category:

mounting accessory

Number Of Horizontal Rows:

3

Adjustment:

adjustable with a pitch of 25 mm

Quantity Per Set:

set of 1

Product Or Component Type:

universal cross rail

Width:

90 mm

Surface Finish:

galvanized

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Fixing Mode:

by screws

China Rohs Regulation:

Pro-active China RoHS declaration (out of China RoHS legal scope)

Reach Free Of Svhc:

Yes

Mounting Support:

adaptation profile, on SM enclosures

Circularity Profile:

N/A

Environmental Disclosure:

ENVPEP110923EN

Device Composition:

fixing elements || 2 cross rails || 4 supports
