Schneider Electric NSYTBS292416HT Abs Ind Box 291X241X168 Hi Tr

(No reviews yet) Write a Review

Write a Review

Schneider Electric NSYTBS292416HT Abs Ind Box 291X241X168 Hi Tr

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

NSYTBS292416HT

UPC:

3.60648E+12

MPN:

Condition:

New

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Depth:

168 mm

Device Composition:

1 body || 1 cover || 4 cover screw

Lock Type:

captive screw flat outside sealed area

Internal Height:

275 mm

Reach Free Of Svhc:

Yes

Removable Parts:

cover by captive screws

Range:

Thalassa

Circularity Profile:

N/A

Electrical Insulation Class:

class II

Ambient Air Temperature For Storage:

-15-40 °C

Width:

241 mm

Ik Degree Of Protection:

IK07 IEC 62262

Toxic Heavy Metal Free:

Yes

Cover Fixing:

plastic screws

Product Or Component Type:

industrial box

Rohs Exemption Information:

Yes

Ambient Air Temperature For Operation:

-25-60 °C

Environmental Disclosure:

ENVPEP2012015EN

China Rohs Regulation:

Pro-active China RoHS declaration (out of China RoHS legal scope)

Mercury Free:

Yes

Product Name:

Thalassa TBS

Type Of Front Cover:

high transparent cover

Standards:

IEC 62208

Warranty:

18 months

Body Type:

one piece moulded

Internal Depth:

160 mm

Net Weight:

1.28 kg

Product Certifications:

TÜV

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Height:

291 mm

Device Application:

multi-purpose

Material:

ABS (acrylonitrile butadiene-styrene)

Internal Width:

225 mm

Color:

Gray RAL 7035) || Transparent

Ip Degree Of Protection:

IP66 conforming to NEMA 4.4X

Fire Resistance:

650 °C IEC 60695-2-11

Sustainable Offer Status:

Green Premium product

Enclosure Mounting:

wall mounted

Datasheet:

View
