Schneider Electric NSYTRP24DBL Push-In Terminal, Double Level, 4 Points Pack of 50

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric NSYTRP24DBL Push-In Terminal, Double Level, 4 Points Pack of 50

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

NSYTRP24DBL

UPC:

3606480533242

MPN:

Condition:

New

Height:

55 mm

Number Of Measurement Input:

4

Width:

5.2 mm

Resistivity:

10000 MΩ.m IEC 60093 || 10000 MΩ.m VDE 0303-T30

Line Rated Current:

20-20 A CSA || 20-20 A cURus || 22-22 A EN/IEC 60947-7-1 || 19.5-19.5 A

Dielectric Loss:

0.01 at 1 MHz IEC 60250 || 0.01 at 1 MHz VDE 0303-T4

Cable Cross Section:

0.14-2.5 mm², flexible without cable end || 0.14-4 mm², solid with cable end || 0.2-2.5 mm², flexible with cable end || 0.2-2.5 mm², solid without cable end

Flame Retardance:

V0 0.8 mm UL 94

[Ue] Rated Operational Voltage:

600 V CSA || 500 V EN/IEC 60947-7-1 || 440 V || 600 V cURus

Ambient Air Temperature For Operation:

-40-130 °C IEC 60216-1 || -40-130 °C VDE 0304-T21

Mercury Free:

Yes

Accessory / Separate Part Category:

connection accessory

Product Compatibility:

Spacial enclosures

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Terminal Block Level:

2

China Rohs Regulation:

Pro-active China RoHS declaration (out of China RoHS legal scope)

Length:

78 mm

Range:

Linergy

Mounting Mode:

clip-on

Creep Resistance:

500 CTI (> 400 kB) IEC 60093 || 500 CTI (> 400 kB) VDE 0303-T30

Product Or Component Type:

terminal block

Connections - Terminals:

1 x push-in upstream || 1 x push-in downstream

Product Name:

Linergy TR

Tool Type:

connection without tool || disconnection flat screwdriver

Toxic Heavy Metal Free:

Yes

Terminal Block Type:

passthrough

Dielectric Constant:

3.7 at 1 MHz

Net Weight:

14.3 g

Rohs Exemption Information:

Yes

Number Of Terminals:

2

Connection Position:

inclined

Quantity Per Set:

set of 50

Product Certifications:

LR || EAC || CSA || GL || cURus || VDE

Material:

polyamide 6/6: insulating case || copper alloy: connector and screw || copper alloy: commoning link || chromium-nickel steel: spring

Dielectric Strength:

1000 V IEC 60243-1

Range Compatibility:

Prisma G || Prisma P || Prisma PH || Prisma Pack || Spacial || Kaedra || Pragma || TeSys

Wire Stripping Length:

10 mm

Device Short Name:

TRP

Reach Free Of Svhc:

Yes

Nominal Cross Section:

2.5 mm²

Surface Resistance:

1000 GΩ IEC 60093 || 1000 GΩ VDE 0303-T30

Color:

Blue
