Schneider Electric NSYTRV22MPE Screw Terminal, Mini, For 15Mm Din Rail, Pack of 50

Schneider Electric NSYTRV22MPE Screw Terminal, Mini, For 15Mm Din Rail, Pack of 50

Schneider Electric
SKU:
NSYTRV22MPE
|
UPC:
3606480532467
$330.00
(No reviews yet) Write a Review
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
Mini terminal block, Linergy TR, green-yellow, 2.5 mm2, protective earth, 2 points, for 15mm din rail, Set of 50
Additional Information
Terminal Block Level:
1
Range Compatibility:
Prisma G || Prisma P || Prisma PH || Prisma Pack || Spacial || Kaedra || Pragma || TeSys
Flame Retardance:
V0 0.8 mm UL 94
Sustainable Offer Status:
Green Premium product
Connections - Terminals:
1 x screw terminal upstream || 1 x screw terminal downstream
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Mercury Free:
Yes
Eu Rohs Directive:
Compliant with Exemptions
Rohs Exemption Information:
Yes
Cable Cross Section:
0.2-4 mm², solid || 0.2-2.5 mm², flexible with cable end || 0.14-4 mm², flexible without cable end
Dielectric Loss:
0.01 at 1 MHz IEC 60250 || 0.01 at 1 MHz VDE 0303-T4
Environmental Disclosure:
ENVPEP2309022EN
Connection Position:
sideways
Length:
30 mm
Quantity Per Set:
set of 50
Product Or Component Type:
mini terminal block
Range:
Linergy
Dielectric Strength:
1000 V IEC 60243-1
Surface Resistance:
1000 GΩ IEC 60093 || 1000 GΩ VDE 0303-T30
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Resistivity:
10000 MΩ.m IEC 60093 || 10000 MΩ.m VDE 0303-T30
Wire Stripping Length:
9 mm
Halogen Content Performance:
Halogen free plastic parts product
Terminal Block Type:
protective earth
Creep Resistance:
500 CTI (> 400 kB) IEC 60093 || 500 CTI (> 400 kB) VDE 0303-T30
Product Name:
Linergy TR
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Height:
34 mm
Device Short Name:
TRV
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Nominal Cross Section:
2.5 mm²
Number Of Terminals:
2
Product Certifications:
ATEX || cURus || IEC-Ex || VDE || CSA || EAC
Ambient Air Temperature For Operation:
-40-130 °C IEC 60216-1 || -40-130 °C VDE 0304-T21
Mounting Mode:
clip-on
Tool Type:
connection screwdriver || disconnection screwdriver
Number Of Measurement Input:
1
Tightening Torque:
0.5-0.6 N.m
Color:
green-yellow
Material:
polyamide 6/6: insulating case
Circularity Profile:
N/A
Product Compatibility:
Spacial enclosures
Width:
5.2 mm
