Schneider Electric ZB5AD204 Selector Operating Head Pack of 5
Schneider Electric
$120.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric ZB5AD204 Selector Operating Head Pack of 5
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This switch head with red standard handle provides an ergonomic interface for controlling your machines. It can easily be installed on compatible selector switch units. It provides an effective manner to set your machine in various operating modes. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP69K. It makes it ideal for operation in harsh environments.
- Shape Of Signaling Unit Head:
- round
- Net Weight:
- 0.017 kg
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Ambient Air Temperature For Operation:
- -40-70 °C
- Range Of Product:
- Harmony XB5
- Reach Free Of Svhc:
- Yes
- Ambient Air Temperature For Storage:
- -40-70 °C
- Rohs Exemption Information:
- Yes
- Station Name:
- XALD 1...5 cut-outs || XALK 2...5 cut-outs
- Protective Treatment:
- TH
- Operator Profile:
- red standard handle
- China Rohs Regulation:
- X
- Mechanical Durability:
- 1000000 cycles
- Cad Overall Width:
- 29 mm
- Device Presentation:
- basic element
- Ip Degree Of Protection:
- IP67 IEC 60529 || IP69 IEC 60529 || IP69K
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Cad Overall Height:
- 29 mm
- Toxic Heavy Metal Free:
- Yes
- Electrical Composition Code:
- C3 6 single front mounting || C4 6 single and double front mounting || C5 5 single front mounting || C6 5 single and double front mounting || C7 4 single front mounting || C8 4 single and double front mounting || C11 3 single front mounting || C15 1
- Mercury Free:
- Yes
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Product Or Component Type:
- head for selector switch
- Mounting Diameter:
- 22 mm
- Overvoltage Category:
- class II IEC 60536
- Environmental Disclosure:
- ENVPEP1710010EN
- Warranty:
- 18 months
- Device Short Name:
- ZB5
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Cad Overall Depth:
- 46 mm
- Product Certifications:
- DNV || UL Listed || LROS (Lloyds register of shipping) || BV || CSA || GL
- Head Type:
- standard
- Sustainable Offer Status:
- Green Premium product
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Sale Per Indivisible Quantity:
- 1
- Ik Degree Of Protection:
- IK06 IEC 50102
- Operator Position Information:
- 2 positions 90°
- Circularity Profile:
- ENVEOLI1710010EN
- Bezel Material:
- dark grey plastic
- Type Of Operator:
- stay put
- Standards:
- CSA C22.2 No 14 || EN/IEC 60947-5-1 || EN/IEC 60947-5-4 || JIS C8201-5-1 || EN/IEC 60947-1 || UL 508 || JIS C8201-1
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Datasheet:
- View
