SMC 13-MGPL32TN-25Z | Clean Room Compact Guide Cylinder MGPL Series 32mm Bore 25mm Stroke TN Non-Rotating Short Travel
SMC
$553.05
The SMC 13-MGPL32TN-25Z is a clean room specification compact guide cylinder from the MGPL series with 32mm bore, TN non-rotating table, and short 25mm stroke. Part number decoded: MGPL = MGPL compact guide cylinder, 32 = 32mm bore, TN = non-rotating table, 25 = 25mm stroke, Z = clean room auto-switch groove. The 13- prefix designates a specific clean room grade.
The 32mm bore with only 25mm stroke creates a high-force, short-travel guided actuator with non-rotating precision. At 32mm bore, the MGPL generates approximately 48N at 0.6 MPa through a precisely guided 25mm stroke. The TN table ensures zero angular play throughout travel. This configuration is optimized for precision short-stroke pressing, clamping, and contact applications where the actuator must deliver consistent force with perfect alignment over a minimal distance.
The MGPL32TN-25Z provides precision non-rotating short-stroke guidance at 32mm bore. For longer strokes at 32mm TN, the MGPL32TN series extends to longer options. For the same bore without TN, the MGPL32 provides standard guide operation. For larger bore TN, the MGPL63TN provides 63mm bore maximum force. For smaller bore TN, the MGPL20TN and MGPL25TN provide reduced-force options. Auto switches mount in the Z groove. Clean series (13-) fluorine grease. RoHS compliant.
- Series:
- 13-MGPL-Z (Clean Room)
- Cylinder Type:
- Compact Guide (Linear Guide)
- Action:
- Double-Acting
- Guide:
- Linear Bearing
- Bore:
- 32mm
- Stroke:
- 25mm
- Feature:
- TN Non-Rotating Table
- Auto-Switch:
- Compatible (Z Groove)
- Clean Room Grade:
- 13-
- Certifications:
- RoHS
