SMC 22-MXS20TN-30A | Copper/Fluorine/Silicon-Free Air Slide Table MXS Series 20mm Bore 30mm Stroke TN Non-Rotating A-Port
SMC
$13.55
The SMC 22-MXS20TN-30A is a copper, fluorine, and silicon-free air slide table from the MXS series with TN non-rotating table. Part number decoded: MXS = MXS series, 20 = 20mm bore, TN = non-rotating table, 30 = 30mm stroke, A = A-port. The 22- prefix designates Cu/F/Si-free construction.
The MXS20TN provides the highest rigidity dual-rod guided slide with non-rotating precision at 20mm bore. At 30mm stroke with Cu/F/Si-free construction, this provides precision non-rotating actuation for the most demanding semiconductor applications. The TN table eliminates all angular play, essential when the slide drives precision tooling or alignment fixtures in front-end fabrication equipment.
The 22-MXS20TN-30A provides Cu/F/Si-free TN MXS at 20mm bore. For the standard clean room MXS TN (13-), the 13-MXS20TN-30 provides the base clean room option. For Cu/F/Si-free MXQ TN slides, the 22-MXQ20TN-125P provides the recirculating ball guide TN alternative. For Cu/F/Si-free MXS without TN, other 22-MXS options may be available. For auto-switch capability, add M9P/M9B suffixes. RoHS compliant.
- Series:
- 22-MXS (Cu/F/Si-Free)
- Actuator Type:
- Air Slide Table
- Guide:
- Precision Dual Rod Linear Bushing
- Bore:
- 20mm
- Stroke:
- 30mm
- Feature:
- TN Non-Rotating
- Port:
- A
- Material:
- Copper Fluorine Silicon Free
- Certifications:
- RoHS
