Turck Rei-E-112Ia0T-2B2500-C Encoder 100012028
Turck
$254.70
Manufacturer's Part Number: 100012028
Incremental Encoder. Efficiency Line. Ident. no.: 100012028. Flange with mounting element, Ã 40 mm. Blind hole hollow shaft, Ã 6.35mm. Optical measuring principle. Shaft material: stainless steel. Protection class IP64 on housing and shaft side. 20
+70 °C. Max. 4500 rpm. 10
30 VDC. Cable connection, 8-pole. Push-pull, with inverted signals. Pulse frequency max. 300 kHz. 2500 pulses per revolution
- Encoder line:
- Efficiency-Line
- Technology:
- Optical
- Output type:
- Incremental
- Shaft Type:
- Blind hole shaft
- Shaft diameter D (mm):
- 6.35
- Flange diameter:
- Ø 40 mm
- Flange type:
- Flange with mounting element
- Resolution incremental:
- 2500 ppr
- Operating voltage:
- 10 30 VDC
- Output function:
- Push-Pull/HTL, with inverted signals
- Electrical connection:
- Cable
- Housing material:
- Aluminium
- Ambient temperature:
- -20 +70 °C
- Protection class shaft:
- IP64
- Protection class:
- IP64
