Terminal block for pluggable modules; 14-pole; with 4-conductor terminal blocks; with orange separator; for DIN-rail 35 x 15 and 35 x 7.5; 2.5 mm
Electrical Data
- Rated continuous current: 10 A
Safety and protection:
- Rated voltage: 400 V
- Rated impulse voltage: 6 kV
- Pollution degree: 3
Connection Data
- Total number of potentials: 2
- Number of connection types: 4
- Connection technology: CAGE CLAMP<sup></sup>
- Solid conductor: 0.08 2.5 mm / 28 14 AWG
- Fine-stranded conductor: 0.08 2.5 mm / 28 14 AWG
- Strip length: 8 9 mm / 0.31 0.35 inch
- Type of wiring: Front-entry wiring
Geometrical Data
- Width: 37 mm / 1.457 inch
- Height from upper-edge of DIN-35 rail: 28 mm / 1.102 inch
- Depth: 73 mm / 2.874 inch
Mechanical Data
- Type of mounting: DIN-35 rail
Material Data
- Color: gray
- Fire load: 1.042 MJ
- Weight: 60.002 g
Commercial data
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918636414
- Customs Tariff No.: 85369010000
The WAGO 280 series feed-through terminal block is a gray, 1-deck/level unit with a pluggable disconnect and a built-in orange separator, closed on both sides. It features 14 feed-through poles accommodating 56 wires (28 clamps on each side) and supports wire sizes from 0.08mm² to 2.5mm² or #28AWG to #14AWG. The terminal block is rated for a current of 10A and utilizes CAGE CLAMP spring connections. It is designed for mounting on a DIN-35 rail (35 x 15 / 35 x 7.5) and has a width of 37mm, equivalent to model 280636.
- color:
- Gray
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 28 mm / 1.102 inch
- fine stranded conductor:
- 0.08 2.5 mm / 28 14 AWG
- fire load:
- 1.042 MJ
- height:
- 73 mm / 2.874 inch
- mounting type:
- DIN-35 rail
- number of connection types:
- 4
- packaging type:
- Box
- pollution degree:
- 3
- rated continuous current:
- 0.416666666666667
- rated surge voltage:
- 6 kV
- rated voltage:
- 400 V
- solid conductor:
- 0.08 2.5 mm / 28 14 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- total number of potentials:
- 2
- weight:
- 60.002 g
- width:
- 37 mm / 1.457 inch
- wiring direction:
- Front-entry wiring
