2-conductor through terminal block; 16 mm²; center marking; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP; 16,00 mm²; blue.
The WAGO 283 series neutral-through terminal block is a blue, single-deck component designed for neutral-through pole (N) connections, accommodating two wires with one clamp each. It supports wire sizes from 0.2mm² to 16mm² or #24AWG to #6AWG and is rated for a current of 76A. Featuring CAGE CLAMP spring connections, it mounts on a DIN-35 rail (35 x 15 / 35 x 7.5) and has a width of 12mm. This terminal block is equivalent to model 283904.
- actuation type:
- Operating tool
- color:
- Blue
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 37.5 mm / 1.476 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.2 16 mm / 24 6 AWG
- fire load:
- 0.536 MJ
- flammability class per ul94:
- V0
- height:
- 94.5 mm / 3.72 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Center marking
- mounting type:
- DIN-35 rail
- nominal voltage iii 3:
- 800 V
- packaging type:
- Box
- rated current:
- 76 A
- rated surge voltage iii 3:
- 8 kV
- ratings per:
- IEC/EN 60947-7-1
- solid conductor:
- 0.2 16 mm / 24 6 AWG
- strip length:
- 16 17 mm / 0.63 0.67 inch
- weight:
- 35.669 g
- width:
- 12 mm / 0.472 inch
- wiring direction:
- Front-entry wiring
