WAGO 757-164
- SKU:
- 757-164
- Condition:
- New
- connection technology inputs outputs:
- 6 x M12 socket: 4-pole: incl. ground
- connection technology trunk cable:
- 1 x M23 plug: 12-pole
- contact resistance max:
- 0.01
- country of origin sales organisation germany:
- DE
- depth:
- 123 mm / 4.843 inch
- encapsulation:
- Fully encapsulated with conformal coating (UL 94 V0)
- halogen free:
- Yes
- height:
- 34 mm / 1.339 inch
- housing material:
- PA 66 (UL 94 V0): RAL 7035: silicon and halogen free
- indicators:
- LED (A) yellow: Signal status (1 x per contact): LED (U) green: Sensor/actuator box status
- insulation resistance:
- 1000 M
- material properties of the connections:
- Contact: CuSn, nickel base-coat plating and 0.8 m gold-plated: Threaded bush: die-cast Zn, nickel-plated: Seal: Viton: 50 mating cycles
- mounting type:
- Screw mount
- note on protection type:
- Per EN 60529 (NEMA 6 & 6P) in the fully locked position with its plugs or protective caps
- packaging type:
- Box
- pollution degree 5:
- 3 per VDE 0110
- protection type:
- IP67
- rated value of electrical isolation:
- 500 V
- shock resistance:
- Per IEC 60068-2-27
- signal characteristic:
- PNP
- supply voltage:
- 10 30 VDC: Rated voltage: 32 V ~ rms
- surrounding air temperature operation:
- -25 80 C
- vibration resistance:
- Per IEC 60068-2-6
- width:
- 60 mm / 2.362 inch
Description
M12 sensor/actuator box; 6-way; 4-pole; M23 connector
View AllClose
- M12 sensor/actuator box, 6-way
- 4-pole (1 signal per contact)
- M23 connector (12ole)
- Green LED operating indicator
- Yellow LED status indicator
- incl. markers (10 pcs)
- incl. M12 protective caps (2 pcs)
