PUSH WIRE connector for junction boxes; for solid conductors; max. 4 mm²; 4-conductor; Brown clear housing; red cover; Surrounding air temperature: max 60°C; 2,50 mm²; multicoloured.
The 4-wire connector from WAGO's 773 series is designed for wire sizes ranging from 1.5mm² to 4mm² and has a rated current of 32A according to IEC standards. It features a transparent brown housing with a red cover and utilizes PUSH WIRE spring connections. This connector is equivalent to the 773604 model.
- actuation type:
- Push-in
- connectable conductor materials note:
- WAGO spring clamp terminal blocks are suitable for solid aluminum conductors up to 4 mm/12 AWG if WAGO £Alu-Plus¥ Contact Paste is used for termination.£Alu-Plus¥ Contact Paste Advantages:Automatically destroys the oxide film during clamp
- color:
- Multicoloured
- connectable conductor materials:
- Copper || Aluminum
- connection technology:
- PUSH WIRE«
- continuous operating temperature:
- 105 C
- country of origin sales organisation germany:
- CN
- cover color:
- Red
- depth:
- 19.5 mm / 0.768 inch
- fire load:
- 0.019 MJ
- flammability class per ul94:
- V2
- height:
- 13.1 mm / 0.516 inch
- legend ratings:
- (II / 2) « Overvoltage category II / Pollution degree 2
- nominal voltage ii 2:
- 400 V
- packaging type:
- Box
- rated current:
- 32 A
- rated surge voltage ii 2:
- 4 kV
- ratings per:
- IEC/EN 60664-1
- solid conductor:
- 1.5 ª 4 mm
- strip length:
- 12 mm / 0.47 inch
- surrounding air temperature operation:
- 60 C
- weight:
- 2.430 g
- width:
- 13 mm / 0.512 inch
- wiring direction:
- Side-entry wiring
