WAGO 788-701 Solid-State Relay Module, 24 VDC Input, 5 A Output, 2-Wire Connection, Red LED Indicator, 15 mm Width
Wago
$74.95
Solid-state relay module; Nominal input voltage: 24 VDC; Output voltage range: 3
30 VDC; Limiting continuous current: 5 A; 2-wire connection; Red status indicator; Module width: 15 mm; gray.
The WAGO 788 series is a plug-in input solid-state relay (SSR) with a pre-assembled socket base and a red LED indicator. It features a 2-wire connection and is designed for single-pole, single-phase applications. The control voltage ranges from 15-30Vdc, with a nominal value of 24Vdc, and the output voltage is rated at 0-30Vdc, also with a nominal value of 24Vdc. The relay can handle a continuous current of 5A and utilizes Push-in CAGE CLAMP connections for secure wiring. It is designed for DIN-35 rail mounting with a 15mm width and has an IP20 protection rating. This relay is equivalent to the model 788701.
- color:
- Gray
- country of origin sales organisation germany:
- DE
- fire load:
- 0.002 MJ
- height:
- 5 mm / 0.197 inch
- packaging type:
- Box
- rated current:
- 24 A
- weight:
- 0.587 g
- width:
- 5 mm / 0.197 inch
