Industrial-ECO-Switch5Port Gb 2-Slot 1000BASE-SX/LX, black
- 5 ETHERNET ports, 10/100/1000 Mbit/s, autonegotiation
- 4 PoE+ ports (IEEE 802.3at)
- 2 SFP slots, 1000 Mbit/s
- Front-panel diagnostic LEDs
- Supports Auto-MDI/MDI-X functions
- Full/half-duplex transfer modes for each port
- Store-and-forward switching method
- Integrated address look-up table, supports up to 8000 absolute MAC addresses
- Overvoltage protection
- IEEE 802.3x flow control in full-duplex mode
- Prioritization of Profinet Ethernet Frame (EtherType=0x8892) according to IEEE802.1p
- For DIN-35 rail
The WAGO 852 series is a 7-port Industrial Eco Gigabit Ethernet network switch designed for robust industrial applications. It features 5 RJ45 ports supporting 1000BASE-T and PoE, and 2 SFP ports for single-mode or multi-mode fiber connections (1000BASE-SX/LX). The switch supports Ethernet/IP communication and operates on a supply voltage of 24-57Vdc. It is designed for DIN-35 rail or wall mounting, has a compact 50mm width, and is rated IP30 for protection. The device can operate in extreme temperatures ranging from -40°C to +70°C, making it suitable for harsh environments.
- baud rate:
- Copper cable: 10/1000 Mbit/s: Fiber optic:1000 Mbit/s
- color:
- Black
- communication standards:
- IEEE 802.3 10BASE-T || IEEE 802.3u 100BASE-TX/FX || IEEE 802.3ab 1000BASE-T || IEEE 802.3z 1000BASE-SX/LX || IEEE 802.3x Flow Control || IEEE 802.3af Power over Ethernet (PoE) || IEEE 802.3at High Power over Ethernet (PoE+) || IEEE 802.1p Prioritizat
- conformity marking:
- CE
- connection technology communication fieldbus:
- Copper cable: 5 x RJ-45: Fiber optic: 2 x SFP: LC fiber-optic connector
- connection technology supply:
- 1 x Built-in male connector: 231-432/001-000: included female connector (MCS Connectors): 2231-102/026-000
- country of origin sales organisation germany:
- TW
- depth:
- 120 mm / 4.724 inch
- emc emission of interference:
- Per EN 61000-6-4
- emc immunity to interference:
- Per EN 61000-6-2
- fire load:
- 0.087 MJ
- height:
- 160 mm / 6.299 inch
- housing material:
- Sheet steel
- indicators:
- Device: LED (PWR) green: Power supply: LED (SFP) green: Status of fiber optic ports: LED (PoE 1 4) green: Power over Ethernet: per port: LED (1000, LNK/ACT) green: Status 1000 Mbit/s, LNK/ACT ports 1 5
- jumbo frame size:
- 10000 Byte
- mac table size:
- 8000 addresses
- mounting type:
- DIN-35 rail
- number of 1000base sx lx ports:
- 2
- number of 1000base t ports:
- 5
- optical fiber type:
- Single-mode and multi-mode
- packaging type:
- Box
- power consumption max:
- 14 W
- power consumption note:
- 134 W with 4 PoE
- protection type:
- IP30
- relative humidity without condensation:
- 0.95
- shock resistance:
- Per IEC 60068-2-27
- supply voltage:
- 24 57 VDC
- surrounding air temperature operation:
- -40 70 C
- surrounding air temperature storage:
- -40 80 C
- topology:
- Star
- transmission medium communication fieldbus:
- Copper cable: Cat. 5e or higher, 100 m maximum cable length: Fiber optic: SX Multi-Mode, LX Single-Mode
- vibration resistance:
- Per IEC 60068-2-6
- weight:
- 780.000 g
- width:
- 50 mm / 1.969 inch
