Datasensing QX3/C0-2A Sensors
Datasensing
$188.89
The Datasensing QX3/C0-2A Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a diffuse reflection function with a nominal sensing distance of 300mm, these sensors are equipped with axial and right-angle optics for versatile application. The sensors boast a fast response time of 0.75-0.5 ms and a high switching frequency of 750Hz, ensuring quick and accurate detection. With NPN-PNP selectable output and a high output current capacity of over 300mA, they are suitable for various industrial environments.
The sensors are built with a robust ABS housing and an acrylic active head, providing durability and protection against harsh conditions. They operate efficiently within a temperature range of -25°C to +70°C and are protected against short circuits and reverse polarity. The LED indicators offer clear status updates, with red indicating output status and green for stability. The sensors are equipped with a 2m PVC cable for easy installation and come with ST70 mounting brackets and screws for secure placement.
With a compact cubic design measuring 15x23x40mm and weighing just 70g, the Datasensing QX3/C0-2A Sensors are CE approved and EMC compatible, meeting EN 60947-5-2 standards. They offer excellent resistance to shocks and vibrations, adhering to IEC 60068-2-6 and IEC 60068-2-28 standards, and provide IP65 mechanical protection, making them ideal for demanding industrial applications.
- Nominal sensing distance:
- 300mm
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (medium distance, ?600mm)
- Optic position:
- Radial 90°
- Output type:
- NPN/PNP Selectable NC
- Output Function:
- NC
- Switching frequency:
- 750Hz
- Response time:
- 666µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 20mA
- Load current:
- ?300mA
- Leakage current:
- ? 100?A @ 30Vdc
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red(output status) , Geen (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Dimensions:
- 15x23x49
- Weight:
- 70g
- Connections:
- 2m PVC cable
- Active Head Material:
- Acrylic
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Material:
- ABS
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST70 mounting brakets and screws
- Dimensions:
- 15x23x40
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
