Datasensing QXP/C0-2A Sensors
Datasensing
$201.18
The Datasensing QXP/C0-2A Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a polarized function principle, these sensors offer a nominal sensing distance of 3 meters with a repeat accuracy of ? 5%. The axial and right-angle optics, combined with a visible red light emission at 660nm, ensure long-distance capability and precision beam alignment.
Equipped with two LED indicators, red for output status and green for stability, these sensors provide clear visual feedback. The NPN/PNP selectable output with NC function allows for versatile integration into various systems. With a fast response time of 666µs and a switching frequency of 750Hz, these sensors are ideal for high-speed applications.
The QXP/C0-2A sensors are built to withstand harsh environments, featuring a robust ABS housing with IP65 mechanical protection and EMC compatibility per EN 60947-5-2 standards. They are resistant to shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-28. Operating efficiently within a voltage range of 10
30VDC, they have a low no-load supply current of ? 20mA and a load current capacity of ?300mA.
Designed for ease of installation, the sensors come with a 2m PVC cable and include ST70 mounting brackets and screws. The compact cubic design, with dimensions of 15x23x40mm and a weight of 70g, ensures a seamless fit into various setups. The sensors operate reliably in temperatures ranging from -25°C to +70°C, making them suitable for diverse industrial applications.
- Nominal sensing distance:
- 3m
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Polarized
- Optic position:
- Radial 90°
- Output type:
- NPN/PNP Selectable NC
- Output Function:
- NC
- Switching frequency:
- 750Hz
- Response time:
- 666µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 20mA
- Load current:
- ?300mA
- Leakage current:
- ? 100?A @ 30Vdc
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red(output status) , Geen (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Dimensions:
- 15x23x73
- Weight:
- 70g
- Connections:
- 2m PVC cable
- Active Head Material:
- Acrylic
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Material:
- ABS
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST70 mounting brakets and screws
- Dimensions:
- 15x23x40
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
