Wago

WAGO 858-158 Pack of 3

SKU:

858-158

UPC:

MPN:

858-158

Condition:

New

bounce time typ:

4 ms

contact material relay:

AgCe

country of origin sales organisation germany:

CN

depth:

28 mm / 1.102 inch

dielectric strength control load circuit ac 1 min:

1.5 kVrms

dielectric strength load load circuit ac 1 min:

1.5 kVrms

dielectric strength open contact ac 1 min:

1 kVrms

drop out time typ:

25 ms

electrical life no resistive load 23 c:

100 x 103 switching operations

fire load:

0.000 MJ

height from the surface:

35 mm / 1.378 inch

inrush current resistive max:

(AC) 15 A / 4 s

limiting continuous current:

0.208333333333333

mechanical life:

20 x 106 switching operations

mounting type:

Pluggable module

nominal input current at un:

10 mA

nominal input voltage un:

AC 120 V

number of changeover switchover contacts:

4

packaging type:

BOX

protection type:

IP20

pull in time typ:

25 ms

recommended minimum load:

12 V / 100 mA

standards specifications:

EN 61810-1

status indicator:

Red LED || Mechanical

surrounding air temperature operation at un:

-25 70 C

surrounding air temperature storage:

-40 80 C

switching power resistive max:

AC 1250 VA: DC (see load limit curve)

switching voltage max:

AC 250 V

weight:

34.200 g

width:

21.5 mm / 0.846 inch
