Description
Safety mat with built in rubber trim, 24 inch x 30inch, with 10m cable with flying leads coming out of long side, made our of Polyurethane, black with Eurodot design. ASK-1T4.4-NP 1x0.75 is a safety mat with cast-in ramp edge trim. The safeguarded area is 750 x 1000 mm. Equipped with 2 x 5 m cables (2 x 0.34 mm2 - PU sheathed), each with a M8 male connector.
JSNA-B Series Information
- Resistant To Common Oils And Chemicals
- Flame And Water Resistant
- 24 Volt, 1/2 Amp Ac Or Dc
- No Joining Strips Required
- Hermetically Sealed
The Safety Mat Is Used As Personal Protection Within The Dangerous Areas Around Presses, Robots, Production Lines, Machines Etc. When Connected To A Suitable Monitoring System Stepping On The Safety Mat Will Immediately Be Detected Causing Dangerous Machine Movements To Be Stopped. This Is Made Possible By The Detection Of Electrical Contacts Closing Within The Sandwich Construction Of The Mat.
Specifications
Item Number: 2Tla858002R5700
Upc: 804325846882
Brand: ABB Jokab Safety
Item Category: Safety Mats
Series: Jsna-B
Mat Thickness: 0.55 Inches
Outer Material: Polyurethane
Contact Rating: 24 V, 100 Ma
Minimum Sensitivity: 33 Lbs (15 Kg)
Environmental Protection: Ip65
Color: Black
H X W X D: 30 In X 24 In X .55 In
Net Weight: 33 Lb
Gross Weight: 33 Lb
