ABB 9T51B0008 Single Phase Transformer, 0.5Kva, 240X480-120/240V, NEMA 3R Weatherproof Enclosure, UL & cUL Listed
ABB
$1,051.23
The ABB 9T51B0008 Single Phase Transformer is designed for reliable performance in various environments, featuring a 0.5Kva capacity and dual voltage options of 240X480-120/240V. Encased in a NEMA 3R nonventilated weatherproof enclosure, this transformer is ideal for outdoor applications. It includes knockouts on the back and bottom for versatile installation and mounting holes on the side for easy access. The wiring compartment is equipped with a ground stud, ensuring safe and efficient connections. With encapsulated copper core and coils, the transformer offers improved termination spacing and ample room for wiring, accommodating a range of UL listed connectors for both copper and aluminum cables. The built-in wall mount tabs facilitate straightforward installation. This transformer is RoHS compliant and meets UL and cUL standards, as well as the seismic requirements of IEEE-693-2005, IBC-2021, and CBC 2022, ensuring durability and safety in demanding conditions.
- Temperature Rating:
- 40
- Frequency Rating:
- 60
- Phase:
- 1
- Output Voltage:
- 120/240
- Standard:
- Yes
- Enclosure:
- NEMA 3R
- Wattage:
- 0.5
- Input Voltage:
- 240x480
- Insulation:
- IS-12
- Spec Sheet:
- View
