ABB E16DU2.7 Electronic Overload Relay - Advanced Motor Protection with Extensive Setting Range and High-Temperature Operation
ABB
$165.17
The ABB E16DU2.7 e16du-2.7 electronic overload relay is a self-supplied device that requires no additional external power supply. It provides dependable and swift protection for motors against overloads and phase failures. Designed for ease of use akin to a thermal overload relay, it is compatible with standard motor applications. This electronic overload relay stands out with its extensive setting range, precise accuracy, and ability to operate in high-temperature environments. Users can select from trip classes 10E, 20E, or 30E, and benefit from features such as temperature compensation, trip contact (NC), signal contact (NO), and the option for automatic or manual reset. It also includes a trip-free mechanism, STOP and Test functions, and a trip indication. The relays are designed to connect directly to contactors, and single mounting kits are available as an accessory.
- Ambient Air Temperature:
- Operation -25 ... +70 °C / Operation Compensated -25 ... +70 °C / Storage -50 ... +85 °C
- Voltage Rating:
- Auxiliary Circuit 600 V AC / DC / Main Circuit 690 V AC
- Product Name:
- Electronic Overload Relay
- Trip Class:
- class 10E / class 20E / class 30E
- Spec Sheet:
- View
