Description
Overview
ABB
Mechanically Interlocked Miniature, BC Series
Item# VBC7-30-10-F01
REV 3P MI CONTACTOR,
Specifications
Item Number:
VBC7-30-10-F01
UPC:
804325397117
Brand:
ABB
Item Category:
Contactors
Subcategory:
Mechanically Interlocked Miniature
Series:
BC
Coil Voltage:
24 VDC
Poles:
3NO
UL Motor Switching (AC3):
9.6 Amps
Termination:
Flat Pin
Auxiliary Contacts:
1NO
General Purpose (AC1):
16 Amps
Max HP 575/600V 3PH:
5 Horsepower
Max HP 460/480V 3PH:
5 Horsepower
Max HP 230/240V 3PH:
3 Horsepower
Max HP 200/208V 3PH:
2 Horsepower
Max HP 230/240V 1PH:
2 Horsepower
Max HP 120V 1PH:
1 Horsepower
Coil Type:
Magnetic
Picture No.:
ABBG_CTRL_VB6-VB7_F
H x W x D:
2.26 in x 3.8 in x 1.83 in
Net Weight:
1 lb
Gross Weight:
1 lb
