ABB FBN16TE020R2 20A Mccb 1P 347V Fbn
ABB
$923.94
The ABB FBN16TE020R2 is a state-of-the-art 20A molded case circuit breaker (MCCB) designed for optimal performance and safety. Featuring a single-pole configuration and rated for 347V, this breaker incorporates advanced design elements such as double-break rotary contact structures and ablative materials that enhance its interrupting capability. With an impressive interrupting rating of up to 150kA, it ensures reliable protection against high fault currents. The FBN16TE020R2 is equipped with a non-user interchangeable thermal-magnetic trip unit and comes with load lugs (R2 suffix), making it suitable for a variety of applications. It does not include line lugs, ensuring a streamlined installation process. This breaker is part of the Record Plus½ series, known for its high kAIC ratings, selective coordination, reduced arc flash energy, and current limitation features. It is UL listed, ensuring compliance with safety standards, and is compatible with common internal accessories for enhanced functionality. Ideal for use in commercial and industrial electrical systems, the ABB FBN16TE020R2 offers robust protection and reliable performance.
- Load Rating:
- HACR
- Interrupt Rating:
- 65kA@240 Vac / 65kA@277 Vac
- Frame:
- FB 100
- Standard:
- E11592
- Amperage Rating:
- 20A
- Number Of Poles:
- 1
- Brand Name:
- Record Plus
- Connection:
- 14-10 AWG
- Trip Type:
- LI
- Spec Sheet:
- View
