Description
Overview
ABB
Miniature Circuit Breakers, S200 Series
Item# S201-C4NA - Circuit Breaker, 1P+N, 4A/277VAC, C, 6KAIC, UL1077 Recognized, DIN Mount
S200 Series Information
- Supplemental Protector
- Use as Overcurrent Protection
- UL 1077 - E76126
- B, C, D, K Trip Characteristics
- AC Rated
- 480Y/277 VAC
- 0.5 to 63 Amps
- Line and Load Terminals Included
- Ring Tongue Styles Available
- Finger Safe Terminals
- Optional Front Mounting Kit
Specifications
Item Number:
S201-C4NA
UPC:
662019173153
Brand:
ABB
Item Category:
Circuit Breakers
Subcategory:
Miniature
Series:
S200
Poles:
1 + Neutral
Amps:
4
UL Standard:
Trip Curve:
Terminal Type:
Screw
Max Voltage:
480 VAC;125 VDC
Shunt Trip:
Optional
Protection:
Supplemental
Auxiliary Switch:
Optional
Undervoltage Release:
Optional
Terminals Included:
Line / Load
Trip Unit:
Fixed Thermal / Fixed Magnetic
Mounting:
DIN Rail
Neutral Pole:
Yes
kAIC @ 240 VAC:
6
CSA Standard:
22.2
IEC Standard:
60898, 60947-2
kAIC @ 120 VAC:
10
kAIC @ 277 VAC:
6
kAIC @ 60 VDC:
10
Alarm Switch:
Optional
Busbar:
Optional
Approvals:
UL;CSA
H x W x D:
3.35 in x 1.38 in x 2.98 in
Net Weight:
9.28 OZ
Gross Weight:
9.2986 OZ
