ABB S202MUC-C32 32A 2-Pole Miniature Circuit Breaker for AC/DC Applications - UL & CSA Approved
ABB
$178.20
The ABB S202MUC-C32 is a high-performance miniature circuit breaker from the S200MUC series, designed for both AC and DC applications. This 2-pole breaker is rated at 32 amps and features a C trip curve, providing reliable thermal magnetic trip protection. It is engineered with a fast breaking time of 2.3 to 2.5 milliseconds and is suitable for reverse feed, ensuring maximum circuit protection. The S202MUC-C32 is equipped with multi-function terminals, a bus connection system, and finger-safe terminals for enhanced safety. It supports DIN rail mounting and offers optional features such as shunt trip, auxiliary switch, undervoltage release, alarm switch, and busbar. With a maximum voltage capacity of 480Y/277 VAC, 250 VDC, and 500 VDC, this circuit breaker is UL and CSA approved, making it a reliable choice for various electrical protection needs. Its compact dimensions of 3.46 x 1.38 x 2.72 inches make it an ideal solution for space-constrained installations.
- Spec Sheet:
- View
